Tempo SLS535 Stabilised Light Source 1310/1550/1625nm Triple Laser
- 1310/1550/1650nm
- Dual and triple lasers available
- Out of band testing at 1625nm and 1650nm
- 270Hz, 1kHz and 2kHz tone
- PC flat polish interface
The compact and rugged Stabilised Light Sources from Tempo round out the latest fibre tool offerings—delivering a stable light source which is critical when testing fibre optical cable and providing adaptability to all industry standard connectors. Features include dual and triple lasers; out of band testing at 1625nm and 1650nm; 270Hz, 1Hz and 2Hz tone; and PC flat polish interface. Models include: SLS520, SLS525, SLS530, SLS535, and SLS536.
| Model: | SLS520 | SLS525 | SLS530 | SLS535 | SLS536 |
| Wavelength (±20nm): | 1310/1550 | 850/1300 | 1310/1490/1550 | 1310/1550/1625 | 1310/1550/1650 |
| Range of Use: |
Singlemode |
Multimode (62.5/125) | Singlemode | ||
| Emitter Type: |
FP |
LED |
FP |
||
| Spectrum Width: |
≤5nm |
+/-40nm |
≤5nm |
||
| Output Power: | ≥0dBm/-1dBm | -20dBm/-21dBm | ≥0dBm/-1dBm | ||
| Output Power Stability: | ±0.05 dB/15min, ±0.10dB/8hr |
±0.05 dB/15min, ±0.15dB/8hr |
±0.05 dB/15min, ±0.10dB/8hr |
||
| MOD Frequency: |
270Hz, 1kHz, 2kHz. |
||||
| Display: | LCD | ||||
| Battery Lifetime: | 60 hours | ||||
| Connector Type: | SC/PC (interchangeable LC, ST, FC) | ||||
| Power Supply: | 9V Alkaline or 1000mAh Lithium Battery/9V AC adapter | ||||
| Operating Temperature: | -10 to 50ºC | ||||
| Storage Temperature: | -20ºC to 70ºC | ||||
|
Relative Humidity: |
0 to 90% (non-condensing) | ||||
| Size: | 155 x 89 x 33mm (6.1 x 3.5 x 1.3”) | ||||
| Weight: | 300g (0.71lbs) | ||||
|
IP Rating: |
IP54 |
||||
|
Vibration: |
5Hz to 150Hz, Amplitude = 0.15mm |
||||
|
Shock: |
Peak acceleration 25g at a pulse duration of 6ms |
||||
|
Compliance: |
CE, FCC, 21 CFR 1040.10 (Laser) |
||||
Specifications subject to change without notice.
