Rigol DL3031A 350 Watt Electronic Load
Rigol DL3000 is a series of high performance and cost-effective programmable DC electronic loads. With a user-friendly interface and superb performance specifications, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. It can be widely used in various industries, such as automotive electronics, aerospace, and fuel cells.
The A Version adds High Resolution, colour display, Improved Slew Rate, communication ports and Digital I/O.
- Total Power 200W
- Max Current 40A
- User Interface Colour
- Max Slew Rate 3.0 A/μs Standard
- Max Frequency 30KHz
- Resolution 0.1 mA Standard
- Digital I/O Standard
- Ethernet Standard
The Rigol DL3000 family of electronic loads are high performance, cost-effective programmable DC electronic load’s. With a user-friendly interface and superb performance specifications, the DL3000 series provides various interfaces for remote communication to meet your test requirements. They can be used in various industries, such as automotive, electronics, aerospace and fuel cells.
There are 4 models in the Rigol DL3000 load family: DL3021, DL3021A, DL3031, DL3031A.
There are differences in the power and current levels as well as the advanced capabilities. Use this table to identify the best configuration for your application.
| DL3021 | DL3021A | DL3031 | DL3031A | |
| Total Power | 200W | 200W | 350W | 400W |
| Max Current | 40A | 40A | 60A | 60A |
| User Interface | Mono | Colour | Mono | Colour |
| Max Current Slew Rate | 2.5 A/μs Standard; 3 A/μs Optional | 3 A/μs Standard | 2.5 A/μs Standard; 5 A/μs Optional | 5 A/μs Standard |
| Max Continuous Mode Frequency | 15 kHz Standard; 30 kHz Optional | 30 kHz Standard | 15 kHz Standard; 30 kHz Optional | 30 kHz Standard |
| Readback Current Resolution | 1 mA Standard; 0.1 mA Optional | 0.1 mA Standard | 1 mA Standard; 0.1 mA Optional | 0.1 mA Standard |
| Digital I/O Triggering | Optional | Standard | Optional | Standard |
| Ethernet Comm. | Optional | Standard | Optional | Standard |
DL3000 Series Datasheet | Photo | Product | SKU | |
|---|---|---|---|
